USING THE DOCUMENT GLASS TO SEND A FAX IN
DIRECT TRANSMISSION MODE
When sending a fax from the document glass in direct transmission mode, only one page can be transmitted.
Keys in the display can be selected with the arrow keys and the [OK] key.
1
Do not place any objects under the original size detector. Closing the automatic document feeder with an object
underneath may damage the original size detector plate and prevent correct detection of the document size.
(3)
AAA AAA AAA AAA BBB BBB BBB BBB
CCC CCC CCC CCC DDD DDD DDD DDD
EEE EEE EEE EEE
FFF FFF FFF FFF
GGG GGG GGG GGG
HHH HHH HHH HHH
2
III III III III
JJJ JJJ JJJ JJJ
• Only one destination can be entered. A one-touch key in which multiple destinations are stored (group key) cannot
be used.
• In addition to specification by one-touch key, a destination can also be specified using a search number. You can
also directly enter a fax number with the numeric keys or look up a destination in a global address book. For more
information, see
(2)
BACK OK
"ENTERING DESTINATIONS" (page 4-19).
Open the automatic document feeder,
place the original face down on the
document glass, and then gently close
the automatic document feeder.
Document glass scale
mark
5-1/2" x 8-1/2"
(A5)
B5
8-1/2" x 11" (A4)
• Align the middle of the original with the tip of the
the middle of the scale on the left side of the document glass.
• Place the original in the appropriate position for its size as
shown above.
• When the original is a different size than the size setting, set
the original size.
☞
SPECIFYING THE SCAN SIZE AND SEND SIZE
Enter the destination fax number.
(1) Select the [Address] key in the base screen.
For the [Address] key, see
MODE" (page 4-8).
(2) Select the one-touch key of the desired
destination.
(3) Select the [Basic Menu] key.
4-37
FACSIMILE
mark at
(page
4-50
"BASE SCREEN OF FAX
