Chapter 2
© Polycom, Inc.
The following five items configurable by the user are:
•
Setup: Defines the H.323 name and extension for the
ViewStation SP. See "Setup," on page 45.
•
Gateway: Defines the gateway speed, prefix and suffix
used for the ViewStation SP. See "Gateway," on page 47.
•
Gatekeeper: Defines the gatekeeper operation parameters
for the ViewStation SP. See "Gatekeeper," on page 48.
•
Dialing Speeds: Defines the videoconferencing speeds for
the ViewStation SP. See "Dialing Speeds," on page 49.
•
QoS: Defines firewall and NAT parameters for the
ViewStation SP. See "Quality of Service (QoS) and
Firewalls," on page 50.
Setup
The H.323 Setup screen (System Info > Admin Setup >
LAN/H.323 > Setup) is used to specify the H.323 or IP name.This
information applies to the H.323 feature included with all models.
The H.323 extension (E.164) is a naming scheme based on the
ViewStation SP serial number. This number MUST be unique to the
ViewStation SP. On ViewStation SP models with ISDN options, an
Auto H.323 Dialing check box appears below the H.323 extension
(E.164) field.
Figure 2-23. H.323 Setup Screen
H.323 name when calling this system: Enter a name in the text
box. This name is displayed on the far-site during a
45
Optional Configurations
ViewStation SP User Guide
