The Graphic User Interface or GUI is designed for ease of use. The
following table is a definition of key icons function:
Icon Name
Text Field
Select Button
Network Connectivity Error
Call Speed Indicators
Network Line Indicator
To enter alphabetic characters,
press the SELECT button on
the remote control.
The purpose of the Text Field is
to enable the user to enter
alphanumeric characters into
the ViewStation SP. Numbers
are entered with the remote
control.
The SELECT button shown is
on the remote control. This icon
serves the same function as the
Enter key.
The Network Connectivity Error
icon indicates severe packet
loss between the near end and
the far end site.
The Call Speed Indicators
illustrate the call speed of the
near end or the far end
ViewStation. Speeds may be set
from the Dialing Speeds
screen. See "Dialing Speeds,"
on page 49.
The Network Line Indicators are
shown when the ViewStation
SP is powered on.
Yellow Box: Checking line
status
Red Down Arrow: Error in
network link
Green Up Arrow: Line is
connected
