Chapter 5
Diagnostics
ViewStation SP User Guide
•
LAN Host Name: The LAN host name is the name assigned to
the ViewStation SP for TCP/IP configuration. To set the LAN
host name, go to System Info > Admin Setup > LAN/H.323 >
LAN/Intranet.
•
IP Address: The IP address assigned to the ViewStation SP is
assigned automatically through a DHCP server or is set
manually (static). To manually set the IP address, go to System
Info > Admin Setup > LAN/H.323 > LAN/Intranet.
•
Software Version: This displays the software version and the
date of the software release. Additional information about the
ViewStation SP software version is located at System Info >
Admin Setup > Software/Hardware > Software.
•
Serial Number: The ViewStation SP serial number is unique to
each ViewStation SP. This number is also located on a bar code
sticker on the bottom of the ViewStation SP unit. This number
cannot be modified.
•
Model: The ViewStation SP model type is displayed.
The User Setup, and Admin Setup icons are covered in User
Setup, on page 23.
The Diagnostics screen is used to check network statistics and
perform various diagnostic tests. The Diagnostics screen is located
at System Info > Diagnostics. The following eight icons can be
accessed through the Diagnostics screen:
•
Network Statistics on page 131
•
Advanced Statistics on page 131
•
Call Status on page 131
•
Color Bar on page 131
•
Audio on page 132
•
Near End Loop on page 132
•
Far End Loop (in H.320 call only) on page 132
•
Reset System on page 132.
System Information and Diagnostics
130
www.polycom.com
