6.2 Recording

CAUTION
① The instrument checks zero point for every recording. If the printer block is manually moved
during recording, a recording position may be dislocated.
② In order to protect the chart paper, dot printing is not performed when the distance between the
previous dot printing position and the next one for an identical channel is less than 0.4 ㎜ in the
chart paper feed direction or less than 0.5 ㎜ in the scale direction.

6.2.1 Recording Colors

Table 6.1 lists the recording colors for each channel in analog recording.
You can select a recording color from 6 colors for every channel.
Table 6.1 Recording Colors(standard)
Channel No.
1
2
3
4
5
6

6.3 How to Record

6.3.1 Starting/Stopping Recording Operation

To start/stop recording, press the "RUN" key.
To stop, hold down the "RUN" key for 3 seconds or more.
"RUN" lamp is unilluminated when step recording.
"RUN" lamp is unilluminated when stop recording.
[Note]
① When the power is turned on, the previous state where you turned off is continued.
② When controlling a start/stop of recording through Digital Input (DI, option), you cannot switch
start/stop with the "RUN" key.

6.3.2 Feed the Chart Paper

The chart paper is fed while the "FEED" key is pressed, and stops when released.
Color
Purple
Red
Green
Blue
Brown
Black
―32―
HXPRM10mnCT001E
