7.1.4 Setting the Chart Speed
Setting Items
Set the chart speed. Select it from the table below.
Table 7.2 Chart Speed (Unit: ㎜/h)
0
1
30
40
160
180
750
900
Operation
Setting
1st/2nd Chart speed
Example) When setting the 1st chart speed to 1500 ㎜/h.
Display
[Note]
When altering the chart speed with the DI option, set the 2nd chart speed.
If the DI option is not attached, setting of the 2nd chart speed becomes invalid.
Display
2
3
4
50
60
75
200
240
300
1200
1500
Operation keys
ESC
3sec
MENU
ENT
PRINT
ENT
PRINT
Operation keys
ENT
PRINT
ENT
―60―
5
10
80
90
360
375
Chart speed
Description
Press the "MENU" key for 3 seconds or more to
enter the setup mode. Use the △ key to display
", and press the "ENT" key.
"
Use the △ key to select the 1st chart speed, and
press the "ENT" key.
Description
Use the △ key to set the 1st chart speed, and press
the "ENT" key.
Press the "ENT" key. To return to the user mode,
hold down the "MENU" key for 3 seconds or more.
15
20
25
100
120
150
450
600
720
