6.3.3 Print Sample

Logging on print example and Alarm on print example
Date/Time
Process variable:
Prints "＊＊＊＊＊"
if skipped.
Scale
Chart speed Chart speed
Logging Print:
Prints date, channel number, process variable
engineering unit and chart speed. The scale is
printed sequentially from 1 channel in printing
color.
[Reference]
Alarm print, Comment print,Date-and-Time print and Record Start/end print becomes waited-state if the other
printing is actuated.
TRM-10C stores up to six items of Alarm Occurrence/Recovery print and five items of Comment/Date-and-
Time/Record Start/Record end print. If printing commands are over, TRM-10C prints a marking "＊" on the end
of the last printing. This mark is meaning of that over items would not be printed.
For priority of respective printing, see next page; Priority in Reference.
[Note]
Logging print will not be the wait printing state. At the start time of Logging print, if the prior Logging print is
printing, the next one cannot print. Prolong the printing interval of Logging print in this case.
Record end print
May.10.06
19:30
1：1.532V
2：2.105V
3：1.856V
4：3.790V
0.000
3CH
100 ㎜／h
Fig. 6.2 Print Sample
―33―
Alarm Print:
Prints alarm occurrence/recovery, channel
number, alarm type, and level. ▲ denotes
alarm occurrence (in red) and ▼ denotes
alarm recovery (in purple), respectively.
May.10.06 20:00End
May.10.06 19：00Start
Record start print
▲ 2L2 19:37
▼ 1H1 19:35
▲ 1H1 19:33
▼ 2L2 19:32
5.000
V
▲ 2L2 19:28
▼ 1H1 19:27
▲ 1H1＊18:25
▼ 2L2 18:24
See [Reference] below
