(6) (Difference)，
Caluclates the input of VOLT, TC, RTD or SCALE, and output.
Example) When subtracting the Ch 1 input data from the Ch 6 input data to set the
difference (0 to 40 mV). Records and displays on Ch 6 "Ch 6 (input) - Ch 1(input)".
Display
(Setting channel)
(Reference channel)
(Zero input value after
difference operation)
(Span input value after
difference operation)
[Note]
An entry of an incorrect numeral displays errors
Press the "ENT" key and re-enter a correct numeral.
About Difference, Sum, and Average
The channel to be set must be larger than the one on which computes the "difference, sum, or
average". When setting Channel 6, for example, you can subtract the Channel 1 to 5 value.
The range and scale of the set channel is the same as the channel on which computes the
"difference, sum, and average".
A range value after the computation cannot exceed the maximum range of the instrument.
Set for the reference channel only the voltage, current, thermocouple, resistance temperature
detector, and their scaling ranges.
(Sum)，
Operation keys
ESC Hold down the "MENU" key for 3 seconds or more
3sec
MENU
to enter the setup mode. Use the △ key to display
ENT
PRINT
"
Use the △ key to select the channel you want to set.
ENT
PRINT
Press the "ENT" key.
Use the △ key to select "
ENT
PRINT
"ENT" key.
Use the △ key to select the "channel you want to
ENT
PRINT
subtract." Press the "ENT" key.
Use the △ key to select a numeral. Use the
PRINT
FEED
to shift a digit. Press the "ENT" key.
ENT
Use the △ key to select a numeral. Use the
FEED
PRINT
to shift a digit. Press the "ENT" key.
ENT
Press the "ENT" key. Setting is completed.
ENT
To return to the user mode, hold down the "MENU"
key for 3 seconds or more.
―54―

(Average)

Description
". Press the "ENT" key.
or
". Press the
key
key
.
or
