8.2.5 Outputting the Status

If the open-link recorder has a data error on its link, it will save the error as a communication error in
the internal status area. The (ESC S) command reads this status. Issuing this command clears the
on-going error.
1) Status Output Command
ＥＳＣ Ｓ（ＣＲ）（ＬＦ）
Receiving this command outputs the status for the command received so far.
2) Status Output
Ｅ Ｒ Ｘ Ｘ ＣＲ ＬＦ
ＸＸ ： ００～１９
Table 8.1 Status output list
Status factor
Status output
ＥＲ ００ Ｃ Ｌ
Ｒ Ｆ
ＥＲ ０１ Ｃ Ｌ
Ｒ Ｆ
ＥＲ ０２ Ｃ Ｌ
Ｒ Ｆ
ＥＲ ０３ Ｃ Ｌ
Ｒ Ｆ
ＥＲ ０４ Ｃ Ｌ
Ｒ Ｆ
ＥＲ ０５ Ｃ Ｌ
Ｒ Ｆ
ＥＲ １６ Ｃ Ｌ
Ｒ Ｆ
ＥＲ １７ Ｃ Ｌ
Ｒ Ｆ
ＥＲ １８ Ｃ Ｌ
Ｒ Ｆ
ＥＲ １９ Ｃ Ｌ
Ｒ Ｆ
：When carring out AD conversion end, it occurs.
A/D END
：It occurs during a communication error or a command error occurs.
Syntax error
：When Paper-empty is found, it occurs.
Paper-empty
(The Paper-empty option has been attached)
Status factor
A/D END Syntax error
○
○
○
○
○
○：The factor from which status is ENABLE.
―91―
Paper empty
○
○
○
○
HXPRM10mnCT001E
○
○
○
○
