11.2.4 Standard Functions

Table 11.4 Standard Functions
Item
Analog indication
Analog recording
Engineering unit indication
Digital display
Logging print
List print
Engineering list print
Affix print
Manual print
Dot print skip
Programming
Memory back up
Alarm
Chart speed
Clock indication
Self diagnostics
Scaling
None
Makes analog recording with 6-color dot.
None
Indicates Channel No., Process variable data, Chart speed, Alarm setting
value on the display.
Prints Date, Time, Scaling, Chart speed, Process variable and
Engineering unit at a programmed interval. With the setting, it is possible
for the synchronous print/Asynchronous print to choose.
Prints Chart speed, Sensor type, Measurement range, Engineering unit,
Alarm setting value, Comment, Printing description, Logging print
ON/OFF, Zone, Partial Compression/Expansion
Prints Channel or Tag, Alarm function, Logging print ON/OFF, Reference
time, Interval, Scaling print ON/OFF, Logging print Sync./Async., Alarm
hysteresis, Burn out, DI function(Option)
Prints Channel number by the analog recording.
Prints Measurement result by key input. Analog recording stops.
Skips recording of an unused channel.
Programs Chart speed, Alarm setting value, Logging, Dot point skip, Date
and Time.
A built-in lithium battery protects the clock function. The battery life is 10
years. (total power off period of the instrument : 5 years)
A non-volatile memory stores setting data and calibration data.
Sets 2 types (H, L) of alarms per channel. Sets a total of 4 level.
Selects Chart speed from 34 types.
Indicates Year, Month, Day, Hour and Minute. Sets the year in A.D, and
adjusts leap year automatically.
Occurring some type of the defect to indicate "E Err＊＊".
(＊＊: type of the defect)
Indicates and record the input of a unification signal etc. is changed into
the engineering scales.
