8.2.4 Outputting the Unit and Decimal Point Position Data

1) Specifying the Unit and Decimal Point Position Data Output
TS2(CR)(LF)
Once this command is received, the recorder transfers the unit and decimal point position data to the
transmit buffer, when the (ESC) T command is received.
2) Updating the Data
(ESC)T(CR)(LF)
Once this command is received, the recorder transfers the update unit and decimal point position
data to the transmit buffer.
3) Outputting the Data
LF,S_CH,E_CH
S_CH :Output start channel
E_CH :Output end channel
※ When the number of channels is one, specify (S_CH) = (E_CH).
Example) LF,01,06(CR)(LF) ············· The unit and decimal point of 01 to 06 channel output.
4) Data Format
(DS
)(DS
)(CHNo.)(UNIT
① DS
:Data information 1 (1 byte)
N
: Normal
D
: Difference computation data
S
: Sum computation data
M
: Average computation data
R
: Square root computation data
C
: Decade computation data,
: Over range (Data = ±99999)
O
S
: Skip (All the data are spaces)
② DS
:Data information 2 (1 byte)
_(Space)
③ CHNo.:Channel number (2bytes) ;
④ UNIT
to
:UNIT
Returns the set unit in terms of code. (When sending the 7-bit data, the higher 1 bit is missing.)
⑤ DP :Decimal point information (1 byte) ;
[Note]
By the range setting, a decimal point position may differ from a display screen.
01
06
to
01
06
to
)(DP)
:Final data,
:Other data
01~06
0~4
―90―
HXPRM10mnCT001E
