11.1.3 Structure

：Panel mount(vertical panel)
Mounting
Allowable backward inclination : Within 30゜
Material(Color) ： Case
Door

11.1.4 Power Source

Rated supply voltage range
Working supply voltage range
Rated power frequency
Working frequency range
Table 11.1 Power consumption
6-dot recorder

11.1.5 Normal Operating Conditions

Ambient temperature
Ambient humidity
Supply voltage
Supply frequency
Vibration
Shock
Magnetic field
Noise
Posture
Warming up time
；Polycarbonate(Black), Glass 10% UL94-V0
；Polycarbonate UL94-V2(Clear)
；Dust-proof, drip-proof (Complies with the IEC60529-IP65) not evaluated
as part of Underwriters Laboratories Listing certification.
：100 to 240V AC
：85 to 264V AC
：50/60Hz
：45 to 65Hz
100VＡＣ Max. power consumption
About 25VA
：0 to 50℃
：20 to 80%RH
：85 to 264V AC
：45 to 65Hz
：10 to 60Hz 0.2m/s
2
max.
：Unacceptable
：400A/m max. (DC and AC: 50/60Hz)
：Normal mode(50/60Hz)
DC current, Thermocouple; Peak value lower than the span width
Resistance temperature detector
Common mode (50/60Hz)
Interchannel maximum noise voltage: 200 V AC at 50/60 Hz
：Allowable backward inclination : within 30゜, Right-and-left level
：30 minutes min. from the time of a power-on injection
―109―
About 30VA
of the measurement range
; 50mV max.
; 250V AC max.
