6.2 Recording

6.2.1 Recording Colors

Table 6.1 shows the recording colors for each channel in analog recording.
Table 6.1 Recording Colors
Channel No.
１
２

6.2.2 Printing Color

Various digital prints are recorded in purple.

6.2.3 Pen Gap

Fig.6.2 shows the gap between No.1 and No.2 pens.
ＣＨ２
（Green）

6.2.4 Gaps between Pens and Printer

Fig. 6.3 shows the gaps between the No.1/No.2 pen and print.
Print
Color
Red
Green
ＣＨ１
（Red）
Fig. 6.2 Gap between Pens
００ ＡＢＣ
２０．５㎜
ＣＨ２
（Green）
Fig. 6.3 Gaps between Pens and Printer
―40―
２㎜
ＣＨ１
２㎜
（Red）
２２．５㎜
