(Square Root)

Caluclates the square root of Volt input, and scaling that value.
Setting the unit is possible. (See 7.1.3 on page 58)
Example) When setting the voltage of 0 to 40 mV and scale of 000.00 to 100.00 for Channel 1.
Display
(Zero input value)
(Span input value)
(Zero-side scale value)
(Decimal point)
(Span-side scale value)
[Note]
An entry of an incorrect numeral displays errors
Press the "ENT" key and re-enter a correct numeral.
Operation keys
Hold down the "MENU" key for 3 seconds or more
ESC
to enter the setup mode. Use the △ key to display
3sec
MENU
"
ENT
PRINT
Use the △ key to select the channel you want to set.
Press the "ENT" key.
ENT
PRINT
Use the △ key to select "
"ENT" key.
ENT
PRINT
Use the △ key to select a range(50 mV). Press the
"ENT" key.
ENT
PRINT
Use the △ key to select a numeral. Use the
to shift a digit. Press the "ENT" key.
PRINT
FEED
ENT
Use the △ key to select a numeral. Use the
to shift a digit. Press the "ENT" key.
PRINT
FEED
ENT
Use the △ key to select a numeral. Use the
PRINT
to shift a digit.
FEED
Press the
to blink a decimal point. Use the △ key to select a
FEED
PRINT
decimal point position. Press the "ENT" key.
ENT
Use the △ key to select a numeral. Use the
to shift a digit. Press the "ENT" key.
PRINT
FEED
ENT
Press the "ENT" key. Setting is completed. To
return to the user mode, hold down the "MENU"
ENT
key for 3 seconds or more.
―50―
