7.2.12 Data Calibration

Calibrate the voltage, resistance temperature detector, and reference junction compensation.
：Calibration of the voltage
：Calibration of the resistance temperature detector
：Calibration of reference junction compensation
[Note]
This recorder is precisely proofread. First of all, please reconfirm a setting value when the instruction value is
abnormal.
The calibration value abnormality doesn't usually occur.
Example) When calibrating the voltage at Channel 1.
Display
[Note]
For calibration for voltage input, only one channel calibration is effective to all the channel.
Operation keys
Enter the engineering mode (See the key operation
ENT
in page 69). Use the △ key to display
ENT
PRINT
"
key to select "
ENT
PRINT
Select the channel where an instrument for
calibration such as a mV generator is connected,
PRINT ENT
and then, press the "ENT" key.
Enter 0 mV. After 30 seconds, make sure that the
ENT
ALM lamp unilluminates and press the "ENT" key.
Enter 15 mV. After 10 seconds, make sure that the
ENT
ALM lamp unilluminates and press the "ENT" key.
Enter 25 mV. After 10 seconds, make sure that the
ENT
ALM lamp unilluminates and press the "ENT" key.
Enter 35 mV. After 10 seconds, make sure that the
ENT
ALM lamp unilluminates and press the "ENT" key.
Enter 55 mV. After 10 seconds, make sure that the
ENT
ALM lamp unilluminates and press the "ENT" key.
Enter 200 mV. After 10 seconds, make sure that the
ENT
ALM lamp unilluminates and press the "ENT" key.
Enter 1 V. After 10 seconds, make sure that the
ENT
ALM lamp unilluminates and press the "ENT" key.
Enter 5 V. After 10 seconds, make sure that the
ENT
ALM lamp unilluminates and press the "ENT" key.
Enter 10 V. After 10 seconds, make sure that the
ENT
ALM lamp unilluminates and press the "ENT" key.
If the calibration is correct, select "
ENT
PRINT
the △ key, and if incorrect, select "
respectively. Then, press the "ENT" key.
―82―
Description
", and press the "ENT" key. Use the △
", and press the "ENT" key.
HXPRM10mnCT001E
