1) Open Command
０１
（ＥＳＣ）Ｏ＿ （ＣＲ）（ＬＦ）
Address (01 to 32)
Space (20 Hex.)
For the host computer to communicate the recorder, it must issue this command and memorize that it
has been issued.
2) Close Command
０１
（ＥＳＣ）Ｃ＿ （ＣＲ）（ＬＦ）
Address (01 to 32)
Space (20Hex.)
For the host computer to communicate with the recorder, this command must be issued to the
open-link recorder, if you want to send the data to the recorders, which have not issued the open
command.

8.2.3 Outputting the Process Variable Data

1) Specifying the Process Variable Data Output
０
ＴＳ （ＣＲ）（ＬＦ）
Once this command is received, the recorder transfers the process variable data to the transmit buffer,
when the (ESC) T command is received.
2) Updating the Data
（ESC）Ｔ（ＣＲ）（ＬＦ）
Once this command is received, the recorder transfers the update process variable data to the
transmit buffer.
3) Specifying the Process Variable Data Output Order (At BINARY Mode Output)
０
ＢＯ （ＣＲ）（ＬＦ）
Outputs starting from the upper byte.
１
ＢＯ （ＣＲ）（ＬＦ）
Outputs starting from the lower byte.
The recorder outputs starting from the lower byte, unless otherwise specified.
4) Outputting the Data
０
ＦＭ ，Ｓ＿ＣＨ，Ｅ＿ＣＨ
ＦＭ １ ，Ｓ＿ＣＨ，Ｅ＿ＣＨ
Ｓ＿ＣＨ :Output start channel
Ｅ＿ＣＨ :Output end channel
※ When the number of channels is one, specify (S_CH) = (E_CH).
Example) FM0,01,06(CR)(LF) ·········· ASCII,01 to 06 channel output.
Specifies the ASCII mode output.
Specifies the BINARY mode output.
０１ ０６
to
０１ ０６
to
