(Current/Voltage),
Measurs Current, Voltage, Thermocouple and RTD.
Example) When setting Thermocouple T for Channel 1(T :-100 to 300 ℃)
Display
(Zero setting)
(Span setting)
[Note]
① An entry of an incorrect numeral displays an error,
Press the "ENT" key and re-enter a correct numeral.
② For the range setting (When especially, don't change a decimal point position at the
thermocouple or in RTD) which doesn't have the necessity of the scaling, don't set a scaling.
(Thermocouple),
Operation keys
ESC
Hold down the "MENU" key for 3 seconds or more
3sec
MENU
to enter the setup mode. Displays "
ENT
then, press the "ENT" key.
Use the△ key to select the channel you want to set.
ENT
PRINT
Press the "ENT" key.
Use the △ key to select the mode.
ENT
PRINT
"ENT" key.
Use the △ key to select the type. Press the "ENT"
ENT
PRINT
key.
Use the △ key to select a sign and numeral.
PRINT
FEED
Use the
ENT
Use the △ key to select a sign and numeral.
PRINT
FEED
Use the
ENT
Press the "ENT" key. Setting is completed.
ENT
To return to the user mode, hold down the "MENU"
key for 3 seconds or more.
―46―

(Resistance Temperature Detector)

Description
key to shift a digit. Press the "ENT" key.
key to shift a digit. Press the "ENT" key.
or
HXPRM10mnCT001E
",
Press the
.
