7.1.7 Setting Other Functions

Setting other functions as follows is possible.
Setting Items
①
(Printing cycle)
Select a printing cycle from among 10, 20, 30, and 60 seconds.
②
(Zone recording)
The data for each channel can be recorded separately in another area so that they will not overlap.
③
(Partial compression/expansion)
Record the measured data of the channel, partially compressed/expanded.
④
(Digital print)
Specify with ON/OFF whether the measured data for each channel is to be printed or not.
⑤
(Tag)
Set the tag, which is to be printed instead of a channel number, for logging print or manual print.
Setting up to 7 characters (select from character code table on page 59), as the tag for each
channel is possible.
⑥
(Comment words)
Set the comment words to be printed by DI. There are three kinds of comment words and setting
up to 16 characters (select from character code table on page 59) for each DI is possible.
Operation
Setting Mode
Printing Cycle
Zone Recording
Partial Compression/Expansion
Digital Print
Tag
Comment Words
