Scaling the VOLT input and displays the index number. Setting the unit is possible. (See 7.1.3 on
page 58)
Example) When setting the voltage of 0 to 5 V and decade of 1.0×10
Display
(Zero input value)
(Span input value)
(Zero-side scale value)
(Span-side scale value)
[Note]
An entry of an incorrect numeral displays errors
Press the "ENT" key and re-enter a correct numeral.
Operation keys
ESC
Hold down the "MENU" key for 3 seconds or more
3sec
MENU
to enter the setup mode. Use the △ key to display
ENT
PRINT
"
Use the △ key to select the channel you want to set.
ENT
PRINT
Press the "ENT" key.
Use the △ key to select "
ENT
PRINT
"ENT" key.
Use the △ key to select a range(5V). Press the
ENT
PRINT
"ENT" key.
Use the △ key to select a numeral. Use the
PRINT
FEED
to shift a digit. Press the "ENT" key.
ENT
Use the △ key to select a numeral. Use the
PRINT
FEED
to shift a digit. Press the "ENT" key.
ENT
Use the △ key to select a numeral. Use the
PRINT
FEED
to shift a digit. Press the "ENT" key.
ENT
Use the △ key to select a numeral. Use the
FEED
PRINT
to shift a digit. Press the "ENT" key.
ENT
Press the "ENT" key. Setting is completed.
ENT
To return to the user mode, hold down the "MENU"
key for 3 seconds or more.
