3.1 Outside Dimensions Drawing and Panel Cutting Dimensions

Unit: mm
(100)
Dimension required
when the door is fully
opened (135゜).
(Wall on the left side).
2 5
Fig. 3.1 Outside Dimensions and Panel Cutting Dimensions
CAUTION
For maintenance and safety of the instrument, it is recommended to secure the spacing larger than the
parenthesized dimensions per unit.
<Front>
2.5
144
CH, NO.
DATA
ES C
RUN
MENU PRINT FEED
RUN
ALM
<Side>
1 5 0
7 MAX
(Panel thickness)
3.5
ENT
(56)
―12―

3. INSTALLATION

<Rear>
137
<Panel Cutting>
200 min
1 3 8
+ 1
- 0
HXPRM10mnCT001E
