Fig. 38: Looping through the control voltage
Exemplary calculation for 3 drive controllers:
Fig. 39: Continuous current
The result I
the connection point.
7.5.5

Specification of the digital/analog inputs/outputs

Digital inputs type A (standard)
The digital inputs comply with IEC 61131-2.
Table 47: Digital inputs type A
Datum
Allowed input voltage
High
Low
Input current
Delay time
Digital inputs (safety technology Safe Torque Off)
The digital inputs comply with IEC 61131-2.
Table 48: Digital inputs (safety technology)
Datum
Allowed input voltage
Current consumption
RE 62312-B, 03.2022
Connecting the Sytronix system SvP 7030 electrically
has to be smaller than the specified current carrying capacity of
D
High
Low
Sytronix SvP 7030 IMC
Unit Min.
V -3
V 15
V -3
mA 2
μs
Unit Min.
V -3
V 15
V -3
mA 2
83 / 186
Max.
30
30
5
5
100 + position
controller clock
cycle
Max.
30
30
5
5
