Sytronix SvP 7030 IMC
114 / 186
Connecting the Sytronix system SvP 7030 electrically
Single-axis (XCS)
Table 89: Single-axis
Example: XCS with ctrlX DRIVEplus + ctrlX CORE
XCS
Option 1:
(safety technology)
Option 2
Option 3
Option Com.
Bosch Rexroth AG
T0 = Safe Torque Off (STO)
M5 = SafeMotion (M5)
EC = Multi-encoder interface
NN = Not equipped
ET = Multi-Ethernet
DA = Digital/analog I/O extension
NN = Not equipped
ET = Multi-Ethernet
X3 = ctrlX CORE
ctrlX DRIVE
ctrlX DRIVE
plus
✓
✓
✓
-
✓
✓
✓
✓
-
-
✓
-
✓
✓
✓
✓
-
-
RE 62312-B, 03.2022
