Connecting the Sytronix system SvP 7030 electrically
7.5
Connecting the Sytronix system SvP 7030 electrically
7.5.1
General information
In this chapter we only describe components that are commonly used in an SvP
system. This description does not cover device variants with CORE, modular
systems, double or multiple devices, SafeMotion. For these components please
observe the mounting instructions in Project Planning Manual R911386579.
Here you can also find notes on accessories such as connector sets, shield
connections, DC bus adapters, touch guards and DC bus chokes.
Bosch Rexroth AG
Lethal electric shock from live parts with more than
WARNING
50 V!
Fatal electric shock!
Before starting work at live components:
−
De-energize installation and secure power switch
against unintentional or unauthorized reconnection.
−
Before accessing the device, wait at least 30 minutes
after switching off the supply voltages to allow dis-
charging.
−
Check that the voltage has fallen below 50 V before
touching live parts!
−
Never operate the drive controller without touch
guard.
RE 62312-B, 03.2022
