7.4.2

Single-axis converter XCS*-W0023

Dimensional drawing
Dimensions, weight, insulation
Table 26: Data for weight, dimensions, insulation
Designation
Weight
Device height
1)
Device depth
2)
Device width
3)
Insulation resistance at 500 V DC
Capacitance against housing
1) 2) 3) Housing dimension; see also related dimensional drawing
Temperatures, cooling, power dissipation, distances
Table 27: Cooling and power dissipation data
Designation
Ambient temperature range for oper-
ation with nominal data
Ambient temperature range during
operation with reduced nominal data
Reduction of P , P
DC_cont
I at T < T < T
out_cont a_work a
Allowed mounting orientation
Cooling type
Volumetric capacity of forced cooling
Allowed switching frequencies
RE 62312-B, 03.2022
Mounting the machine control cabinet components
Symbol
m
H
T
B
R
is
C
Y
Symbol
T
a_work
T
a_work_red
BD
f
Ta
a_work_red
V
f
1)
s
Sytronix SvP 7030 IMC
Unit XCS*-W0023
kg
mm
mm
mm
MOhm
nF
Unit XCS*-W0023
°C
°C
%/K
Forced ventilation
m /h
3
kHz
53 / 186
tbd
309
196.5
50
1
2 × 100
0 ... 40
40 ... 55
2
G1
36
4 ... 16
