Bosch rexroth Sytronix SvP 7030 IMC Operating Manual page 149

XG31, digital inputs, digital outputs, analog input
Table 118: Function, pinout, properties
View
Spring terminal (con-
nector)
Connection cable
stranded wire
Stripped length
Connectors included in scope of delivery.
The technical data can be found in technical document R911386579.
Fig. 60: Shield connection for analog inputs
A
B
IS
OS Overall shield of the connection cable
RE 62312-B, 03.2022
Connecting the Sytronix system SvP 7030 electrically
Connec- Signal name
tion
1 I_1
2 I_2
3 I_3
4 0V
5 0V_100
6 I_4
7 I_5
8 I_6/O_1
9 I_a_1+
10 I_a_1-
Unit min.
mm 0.2
2
AWG 24
mm -
Analog input of drive controller. Only connect the inner shield of the con-
nection cable to the drive controller if GND has not been connected to
ground in the external device.
External device
Inner shield of the connection cable
Sytronix SvP 7030 IMC
Function
Digital input
(type B) Controller parameter 0
Digital input Controller parameter 1
GND reference
Analog input
Connection for inner
cable shield
Digital input Master/slave switching
Digital input
Digital input/output
Analog differential
input
max.
1.5
16
10
149 / 186
Default assignment
Enable
-
-
Error reset
Error
Actual pressure value
Bosch Rexroth AG
