Sytronix SvP 7030 IMC
26 / 186
Overview of components
Short type designation 1 2 3 4 5 6 7 8 9
Example: X C S 2 - W 0 1 0 0 A B N - 0 1 N E T T 0 E C N N - S 0 3 R S N 1 S V P S 0 N N
⑨
Communication:
ET = Multi-Ethernet with RJ45
X3 = ctrlX CORE
⑩
Hardware option 1 - Safety:
T0 = Safe Torque Off (STO)
M5 = SafeMotion (M5)
⑪
Hardware option 2:
EC = Multi-encoder interface
NN = Not equipped
⑫
Hardware option 3:
NN = Not equipped
ET = Multi-Ethernet
DA = Digital/analog I/O extension
⑬
Runtime type:
S = Standard
⑭
Runtime version:
03 = Version 03 (XCS2)
⑮
Runtime release:
RS = Current release
⑯
Export licenses required:
N = No (maximum output frequency < 599 Hz)
⑰
Protocol - communication:
0 = Defined via ctrlX CORE apps (XCS2)
1 = Sercos III
2 = EtherCAT (SoE)
4 = PROFINET IO
⑱
Technology function
SvP = Servo-variable pump
⑲
Scope of functions, Runtime:
N = DRIVE Runtime
P = DRIVE Runtime Productivity
S = DRIVE Runtime System Extension (required for SvP)
⑳
Scope of functions, SafeMotion:
0 = Hardware option 1 ≠ SafeMotion
3 = SafeMotion Speed
5 = SafeMotion Position
A Other design:
NN = None
Bosch Rexroth AG
1
0 1 2 3 4 5 6 7 8 9
① ② ③ ④ ⑤ ⑥
2
0 1 2 3 4 5 6 7 8 9
⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭
3 4
0 1 2 3 4 5 6 7 8 9 0
⑮ ⑯ ⑰ ⑱ ⑲ ⑳ A
