Sytronix SvP 7030 IMC
122 / 186
Connecting the Sytronix system SvP 7030 electrically
Occurring current load and minimum
required connection cross section
Occurring voltage load
XD01, mains connection (120 mm
Table 96: Function, pinout, properties
View
Terminal block
Connection cable
stranded wire
Thread
Tightening torque
Occurring current load and minimum
required connection cross section
Occurring voltage load
XD02, L+ L -, DC bus connection
Function, pinout
The DC bus connection connects
● multiple drive controllers to one another
● one drive controller to a DC bus capacitor unit (to backup the DC bus
Bosch Rexroth AG
)
2
Identifi-
cation
L1
L2
L3
Unit
mm
2
AWG
Nm
voltage)
See technical data of device used (I
See technical data of device used (U
Function
Connection to power grid (L1)
Connection to power grid (L2)
Connection to power grid (L3)
min.
1×16, 2×16
1×6, 2×4
M10
16
see technical data of device used (I
see technical data of device used (U
and A
)
LN
LN
or U
)
LN
LN_nom
max.
1×120, 2×120
1×4/0, 2×4/0
20
and A
)
LN
LN
or U
)
LN
LN_nom
RE 62312-B, 03.2022
