Sytronix SvP 7030 IMC
140 / 186
Connecting the Sytronix system SvP 7030 electrically
XG03 (2.5 mm
Table 110: Function, pinout
View
Spring terminal (connector)
Connection cable
stranded wire
Stripped length
Current carrying capacity of out-
puts XG03
Time constant of load
Number of switching actions at
maximum time constant of load
Switching frequency
Short-circuit protection
Overload protection
Bosch Rexroth AG
)
2
Connec-
tion
5
6
7
8
Unit
mm
2
AWG
mm
A
ms
Hz
XG03.7 against XG03.8 (output for controlling the
Signal name
MotTemp+
MotTemp- Motor temperature evalu-
+24VBr
0VBr Controlling the motor
min.
0.2
24
10
-
-
Wear-free electronic contact
-
motor holding brake)
Function
Input
ation
Output
holding brake
max.
2.5
12
2
50
0.5
RE 62312-B, 03.2022
