Table 51: Digital outputs
Datum
Output voltage ON
Output voltage OFF
Allowed output current per
output
Allowed energy content of con-
nected inductive loads, e.g.
relay coils
Capacitive load
Short-circuit protection
Overload protection
Block diagram, output:
Fault detection
1) At a maximum switching frequency of 1 Hz
2) In the case of inductive loads with currents > 200 mA or in the case of
inductive loads with a greater energy content, an external free-wheeling arm
has to be installed. The effective terminal voltage has to be < 25 V.
3) n
Table 52: Time behavior
Designation
Test pulse width (t
Cycle duration (T
Phase shift between two test
pulses on both channels (φ)
RE 62312-B, 03.2022
Connecting the Sytronix system SvP 7030 electrically
: Number of digital inputs that are used for a digital output
DI
)
PL
)
P
Sytronix SvP 7030 IMC
Unit Min.
V U - 1
ext
V
mA
mJ
nF
Present
Present
The following errors are recognized:
● Wiring error with short-circuit to High
● Wiring error with short-circuit to Low
● Wiring error with short-circuit between the
two channels
● Internal error
In the event of an error, the control panel dis-
plays an error message: F830x, F3134
Unit
μs
ms
°
85 / 186
Max.
U
ext
5
350
400
1) 2)
50 × n
DI 3)
Typ.
400
500
180
