7.4.11
Single-axis converter XCS*-W0280
Dimensional drawing
Dimensions, weight, insulation
Table 44: Data for weight, dimensions, insulation
Designation
Weight
Device height
1)
Device depth
2)
Device width
3)
Insulation resistance at 500 V DC
Capacitance against housing
1) 2) 3) Housing dimension; see also related dimensional drawing
RE 62312-B, 03.2022
Mounting the machine control cabinet components
Symbol
Unit
m
kg
H
mm
T
mm
B
mm
R
MOhm
is
C
nF
Y
Sytronix SvP 7030 IMC
XCS*-W0280
27
340.5
196.5
350
1
2 × 100
Bosch Rexroth AG
71 / 186
