Sytronix SvP 7030 IMC
138 / 186
Connecting the Sytronix system SvP 7030 electrically
Function
The connection point contains the connections for
● monitoring the motor temperature
● controlling the motor holding brake
Overview
Spring terminal at connector (
Component
XCS
1) Hybrid connection (motor, motor temperature monitoring and motor holding brake)
Bosch Rexroth AG
Risk of damage to device from excess voltage at motor
NOTICE
temperature evaluation input!
Only the allowed control voltage for the device is
allowed at the motor temperature evaluation input.
Excess voltage at the input may damage the device.
XG03 (2.5 mm
)
2
0100...W0280
2)
).
XG03 (1.5 mm
)
2
0054...0090
3)
2) Connectors included in the scope of delivery
3) Connectors not in the scope of delivery.
XZ03
(1.5 mm
)
1)
2
0023
3)
RE 62312-B, 03.2022
