Bosch rexroth Sytronix SvP 7030 IMC Operating Manual page 163

LED: Color / flashing pattern
flashing orange/green
flashing orange/green
Flashing green
flashing red/orange
Flashing red-green
Permanently lit red
flashing orange
flashing red
1) Flashing pattern: One square corresponds to a duration of 250 ms; the arrow marks the end of
a cycle; abbreviations on the squares: GN = LED permanently lit green, OG = LED permanently lit
orange, RD = LED permanently lit red, -- = LED is off
2) Display priority (1 = highest priority); the state of the highest priority is displayed
3) NRT = None Real Time
4) MST = Master synchronization telegram
RE 62312-B, 03.2022
Description
1)
HP1 (hot-plug phase 1 active)
HP2 (hot-plug phase 2 active)
Transition from Fast forward to Loopback
Application error
(sub-device/device error [C1D])
MST Warning
4)
(S-0-1045, Sercos: Device status word [S-Dev],
bit15)
Communication error
(sub-device/device error [C1D])
Identification
(S-0-1044, Sercos: Device Control [C-Dev], bit15)
Internal watchdog
Sytronix SvP 7030 IMC
Sercos/EtherCAT
Bosch Rexroth AG
163 / 186
Prio
2)
6
6
5
4
3
2
1
0
