Sytronix SvP 7030 IMC
130 / 186
Connecting the Sytronix system SvP 7030 electrically
Accessories Shield connection:
● XCS2-W0100/120: XAS2-002-003-NN
Typical motor cable cross section: 1 × 16 mm:
Double wiring with 2 × 10 mm
XD03, motor connection (50 mm
Table 101: Function, pinout, properties
View
Terminal block
Connection cable
stranded wire with ring cable lug
Bosch Rexroth AG
Demounting
● Put screwdriver (torx T20) into the opening
of the cable feedthrough and carefully push it
down as far as possible and keep it pushed.
● First move cable feedthrough up and then
pull.
is possible using twin wire end ferrule.
2
)
2
Identifi-
cation
A1
A2
A3
Unit
mm
2
1)
2
Function
For power connection U1 at motor
For power connection V1 at motor
For power connection W1 at motor
min.
1×50
2×25
max.
RE 62312-B, 03.2022
