Offset on DIAPER FEEDER
Devices
We remind you that, prior to confirm the offset execution, it is necessary to remove the yarn from the
loading cell.
The offset operation on TS55 sensors may also be executed on SM-DIN/DUOLOOP Board (parameter
P06) – see paragraph "Configuration of SM-DIN/DUOLOOP Board" on Section 1.
Offset on TS55 and/or DIAPER FEEDER Devices
Select DF OFFSET
Select the device range on which you want to carry out the
offset operation (in this example: DIAPER FEEDER
devices on 003 and 004 positions).
Confirm the selection.
OFFSET
range,
BACK to return to previous screen without performing the
offset operation,
EXIT to return to setup menu.
A temporary
the SERVICE
This error message indicates that an error occurred during the offset
procedure on DIAPER FEEDER devices.
In this case you may repeat the operation (RETRY), ignore the error
(IGNORE) or cancel the operation (CANCEL).
MATRIX CUBE
to carry out the operation on selected device
OFFSET EXECUTE
menu will be resumed.
window will appear, then
