1.8 DIAPER FEEDER Interface

TS44
SM/IN - SM/OUT Connectors for DIAPER FEEDER devices daisy chain connection
EXT
UNICO
IS3..
Power supply voltage
Maximum absorption
STOP Outputs: relay contacts (NO)
Opto-insulated Inputs
Max. voltage (Inputs/Output)
Programmable yarn tension
Programmable alarms
Integrated keypad
Signaling
Dimensions
Operating temperature range
Storage temperature
Tension range
Useful tension range
Max applicable tension
Connector for TS44 tension sensor connection
Connector available for future expansions
Connector for intelligent accessory connection
Connector for spool change sensor connection
DIAPER FEEDER Device Technical Characteristics
MATRIX CUBE
Installation and Connections
24 VDC ± 10% or 24 VAC ± 20%
0.2 A (during normal operation)
1 A (under stress)
3 A (at start-up)
0.3 A 125 VAC
1 A 30 VDC
0-24 VDC
VIL Max 1.2 VDC
VIH Min 5 VDC
30 VDC
0.5 ÷ 100.0 gr. (resolution 0.1 gr.) or
5 ÷ 1,000 gr. (resolution 1 gr.)
Depending on the type of TS44 sensor used
0.1 ÷ 10 sec.
3 push-buttons + STOP red LED
With LCD graphic display
290 x 86 x 94 mm
10° - 60 °C
-25° - +85° C
0 / full scale
0% - 95% full scale
10 times the full scale value
