btsr MATRIX CUBE Operating Manual page 108

P3 Programming Level
The P3 programming level allows you to setup 4 functionality:
1) Offset reading/execution and Auto Offset enabling;
2) Device operation mode;
3) Access code to programmable function;
4) DIAPER FEEDER identification code.
to select the P3 level.
to continue.
OFFSET
P3.1
By "offset" we means the calibration of the TS44 sensor's mechanical clamping
position.
It clears possible measurement errors due to the different clamping position of the
device on machine. The displayed indication is the actual
from the clamping position of the device.
While lifting the yarn above the loading cell, press
stored value corresponds to the actual
OFFSET
different, press briefly
You may either enable or disable the Automatic Offset function keeping
pressed for 3 seconds. If the function is disabled, then
the display.
If it is enabled, then at every machine stop the device loosens the yarn until this is
completely relaxed and it carries out an automatic correction of the Offset value.
You are recommended to enable the Auto Offset function only for low
tensions (lower than 1.0 grams).
Auto-Calibration of the Loading Cell
Holding down for 3 seconds you may activate the loading cell Auto-
Calibration function which brings back the Offset value to 5.0 grams (factory
calibration value of DIAPER FEEDER devices).
During the auto-calibration process, an "
shown on the display.
to select the next parameter.
The auto-calibration function can be carried out only when using theTS44..
sensor (not available on TS4.. sensor).
MATRIX CUBE
LFA m/min ADVANCED
OFFSET
to align them.
-
OFFSET INT
DIAPER FEEDER Device
MENU P3
value resulting
OFFSET
to check whether the
value. If the two values are
does not appear on
AUTO
" message is temporarily
CALI
