IS3.. Sensor (spool change detection) Technical Characteristics
Power supply voltage
Absorption
STOP output
STOP output protection
Maximum Current of STOP output
Reaction Delay
Sensitivity
Signaling
Dimensions (mm)
Operating temperature range
Storage temperature
TS55 Sensor Technical Characteristics
Power supply voltage
Absorption
Operating temperature range
Storage temperature
Tension range
Useful tension range
Max applicable tension
Drift error
Repeatability error
Max linearity error
12 .. 24 Vdc ± 20%
15 mA (max 20 mA)
NPN
Protection against over-voltages/short-
circuits
200 mA continuous; 500 mA pick
Programmable from 5 to 1000 msec
Programmable (10 levels)
With integrated LEDs
25 x 10 x 36.3
10° - 60 °C
-25° - +85° C
12 .. 24 Vdc ± 10%
20 mA (max)
10° - 50 °C
-25° - +85° C
0 - full scale
0% - 95% full scale
10 times the full scale value
0.05% / °C
0.5%
2% (0 - full scale)
MATRIX CUBE
Installation and Connections
- 12 -
