SMDIN Software Upgrade

This function allows you to upgrade the SM-DIN/DUOLOOP Board software. Such operation must be carried
out after a possible upgrading of SMART MATRIX CUBE software via PC. The software downloaded from
PC contains, infact, also the part related to the SM-DIN Board.
→
SETUP
Enter the SETUP menu.
Select SERVICE.
Select SMDIN UPG.
Select YES to start the upgrading.
During the upgrading process, the bottom bar indicates the
progressive percentage of upgrade.
At the end of the upgrading process, the
automatically resumed.
To return to SETUP menu.
MATRIX CUBE
SMDIN Software Upgrade
→
SERVICE SMDIN UPG.
SERVICE menu is
- 53 -
