1.1 Creel Assembly

The following figure shows the details for a correct assembly of the creel modules.
6
3
A
B
C
No. Description
1 MATRIX CUBE creel module
2 Separating panel
3 Centering pin
4 Bed frame with casters
5 MASTER CUBE electrical box
6 SMART MATRIX CUBE terminal
7 MATRIX CUBE wheel assembly
MATRIX CUBE
Installation and Connections
C
B
7
Code
MCC/MCC/001
ST.4.048
ST.2.374
MCC/BCS/001
MCC/MCB/001
MCC/SMC/001
MCC/MCW7001
3
2
1
2
1
A
2
1
2
4
5
