Faults
The machine is not
stopped by DIAPER
FEEDER device in
case of yarn breakage
The DIAPER
FEEDER device does
not communicate with
SMART MATRIX
CUBE terminal
ASC1010 COM-
ERROR displayed on
DIAPER FEEDER
display
ASC1010 EEP-
ERROR displayed on
DIAPER FEEDER
display
WATCHDOG
displayed on DIAPER
FEEDER display
Even if the torque of motor driving the roller rotation is very low and does not involve hazards for
the operator safety, it's always advisable to lock the motor prior to operate on the devices (yarn
threading, tilt adjustment of coil separation element, etc.) in order to avoid unexpected motor
startup events.
To lock the motor, just press the
of buttons' red LEDs and of TS44 sensor. At the end of the operation, press again the
and make sure that all the red LEDs turn off.
If the fault is not included in the above table, please contact your local BTSR reseller, giving a
detailed description of the kind of fault and the conditions in which it occurred. Should be
necessary to call the BTSR Technical Service Department, read the code printed on the faulty
device, as this information could be useful to BTSR technicians.
Example:
Device code: DIAPER FEEDER ........................
Causes
1) The third parameter of the P1
programming level has been
de-activated (OFF)
2) Wiring problem.
1) The identification code of
DIAPER FEEDER device is
not correct
2) Failure on SMART MATRIX
CUBE terminal
3) Wiring problem
1) Missing communication
between main DSP and
loading cell DSP.
1) Loss of calibration data
1) Device internal error
button on the DIAPER FEEDER device and check the lighting
MATRIX CUBE
DIAPER FEEDER Device
Solutions
1) Confirm the correct programming of DIAPER
FEEDER parameters. Check the correct
connection of P1-P2 inputs.
2) If the red LEDs on DIAPER FEEDER device
turn on when the yarn breakage occurs, than
check for correct machine connections.
To check the correct operation of the
DIAPER FEEDER STOP output press the
"Control " button and confirm the
lighting of red LEDs; if this does not
occur please contact your BTSR reseller
(it could be necessary to send the device
to the BTSR repair centre).
1) Check that the parameter corresponding to the
identification number (parameter P3.4) is
correct; if necessary carry out the numbering
procedure using the SMART MATRIX CUBE
terminal or set directly the identification code
on DIAPER FEEDER device (parameter P3.4).
2) Check the correct operation of SMART
MATRIX CUBE terminal using the numbering
procedure described in the SMART MATRIX
CUBE manual.
3) Check the overall device wiring.
1) Reset the alarm; if the problem persists,
contact your BTSR reseller.
1) Reset the alarm; if the problem persists,
contact your BTSR reseller.
1) Reset the alarm; if the problem persists,
contact your BTSR reseller.
button
