In particular cases, up to 6 modules can be stacked, adopting particular precautions to ensure creel stability
and operator safety during cleaning, spool replacement, maintenance operations, etc .
For more information, please refer to Section 1.
Manual Objectives
This manual has been written to provide the users of MATRIX CUBE system with the essential information
required to:
•
Correctly install and connect the various system components (creel items, SMART MATRIX CUBE
terminal, SM-DIN/DUOLOOP control Board, DIAPER FEEDER devices, TS55 sensors, etc.)
•
Configure the system according to the application needs and setup the various operation
parameters.
•
Detect and interpret the error signaling and system efficiency data
•
Use the diagnostics maintenance and utility functions offered by the system (system component
test, firmware upgrading, etc.).
How to Use this Manual
The manual is subdivided into 5 sections plus an appendix:
Section 1 – includes the connection diagrams and the electrical interface of the various system
components as well as the instructions for a correct assembly and loading of creels.
Section 2 – provides the operating instructions for a correct use of the SMART MATRIX CUBE terminal
as well as the parameter configuration/programming instructions
Section 3 – lists the possible error messages.
Section 4 – provides detailed information about the DIAPER FEEDER device.
Section 5 – provides the information needed for a correct preventive maintenance of the system.
Appendix A – provides an example of preliminary control procedure (Sign OFF) to be carried out at system
reception time.
Symbols Used
This symbol indicates a safety prescription that must be absolutely adopted to avoid possible
risks of injury.
This symbol is used to point-out notes, warnings and other important information.
→
SETUP IDENTIFY
In the SMART MATRIX CUBE terminal function descriptions, this symbol
indicates the function (e.g. IDENTIFY) within the menu item (SETUP).
