- Source of the signal which defines the switching between machine
stopped and machine running and vice versa
SWITCH)
Possible values: EXT
EXT = External signal provided by the machine
AUTO = signal directly connected to the motor rotation speed.
The machine is considered running when the motor speed is
higher than the threshold value set on the following parameter
(AUTO SWITCH SPEED).
The AUTO SWITCH SPEED
START/STOP SWITCH
AUTO SWITCH SPEED
when the motor speed is higher than the value set to this
parameter (possible value 1 to 200 m/min – default 100)
- Example: AUTO SWITCH SPEED
On the TEN.CTRL window you may program the following options:
TENSION CTRL
- OFF (tension control disabled)
- EXT (tension control enabled/disabled depending on the
Start/Stop signal status)
- AUTO (tension control automatically enabled when at least one
DIAPER FEEDER motor is turning, and disabled when all
the motors are stationary).
MOTION CTRL
Through the MOTION CTRL
yarn breakages, downstream the TS55 sensors, if these are not
detected by the sensor itself because the yarn still actuates the
sensor within the programmed tension range. The following options
are available:
- OFF (motion control disabled)
- 1..60 sec (after the time set on this parameter, if at least one
DIAPER FEEDER motor is not turning, thus indicating
that at least one yarn is broken, an error message
(YARN STITCH – POSITION
When you select
will appear
TLOW TIME (s), THIGH TIME
DELAY
sensors after the machine startup (1 to 60 s).
The sensors will start controlling the tension only
after the set time (time required to allow the machine
reaching the rated speed).
MATRIX CUBE
or AUTO – default EXT).
screen appears only when the
parameter is set to AUTO.
= the machine is considered running
parameter set to 120 m/min.
option it is possible to detect possible
NN) is displayed.
EXT or AUTO, further parameters
(DELAY CTRL, TLOW %, THIGH %,
(s)).
CTRL: Control activation delay by TS55
Style Programming
(START/STOP
