3) Exclusion and Re-inclusion of a DIAPER FEEDER Device
4) Control of Temperature and Current Absorbed by DIAPER FEEDER
When needed, it is possible to temporarily exclude a DIAPER FEEDER device, in
order to avoid undesired starts due to vibrations, etc. To exclude and re-include a
device, operate as follows:
Exclusion:
Press and hold down for 3 seconds
The display will show the exclusion confirmation request.
to confirm the exclusion .
to cancel the operation .
The <<OFF>> indication, shown on display indicates that the device is
currently excluded.
Re-inclusion:
To re-activate the device press and hold down for 3 seconds
to confirm the re-inclusion .
to cancel the operation .
In order to temporarily de-activate a DIAPER FEEDER device simply press
. The condition of device temporarily de-activated is signaled by the
lighting the red LEDS inside the 3 push-buttons and inside theTS44 tension
sensor.
At any time, pressing the
of the control board (32°C in the example below) and of the motor (31°C in the
example below), as well as the current absorbed by the motor (C) in Ampere (0.1 A
in the example below).
MATRIX CUBE
DIAPER FEEDER Device
:
button, you can check the internal temperature (T)
.
