btsr MATRIX CUBE Operating Manual page 120

Cleaning the counter- wheels along the yarn path
Cleaning the TS55 Sensor assembly
For cleaning operations, do not use solvent, but exclusively a vacuum cleaner, a soft cloth
dampened with neutral detergent and a compressed air blow.
Diaper-Feeder Devices
4
1) Motor Driven Wheel
2) Yarn separation column
3) TS44 Sensor
4) Yarn-guide reel
3
5) Yarn way sheave
1
2
5
Wheel assembly
TS55 Sensors
MATRIX CUBE
Preventive Ordinary Maintenance
- 98
