btsr MATRIX CUBE Operating Manual page 111

BAUDRATE
P4.3
This parameter allows you to setup the communication speed on the
DIAPER FEEDER serial interface.
[Allowed values: 57600 or 115200]
or to choose the desired speed.
to confirm the speed shown on display and move to the next parameter.
APPLICATION SELECTION
P4.4
This function allows you to choose one of the pre-defined applications.
or for MATRIX CUBE system the application is predefined: DIAPERS.
to confirm the application shown on display and move to the next parameter.
YARN TYPE
P4.5
This function allows you to set the yarn characteristics.
or to choose between
to confirm the application shown on display and move to the next parameter.
* The mode allows a better handling of bare elastic yarns.
ELASTIC
LANGUAGE SELECTION
P4.6
This function allows you to select the language used to display menu items,
messages and errors.
or to scroll forward/backward the list of available languages:
– –
ITALIANO ENGLISH FRANCAIS
to confirm the language indicated on display and return to the beginning of P4
menu.
SIGNAL POLARITY
P4.7
This function allows you to setup the polarity of
to toggle the
INPUT
to toggle the
STOP
to confirm the option shown on display and move to the next parameter.
MATRIX CUBE
* or
ELASTIC ALL YARN
– –
ESPANOL DEUTSCH
INPUT
signal between NO and NC.
signal between NO and NC.
DIAPER FEEDER Device
options.
–
JAPANESE
and signals.
STOP
- 91 -
