DIAPERFEEDER IP54 Device Technical Characteristics
Power supply voltage
Maximum absorption
STOP Outputs: relay contacts (NO)
Opto-insulated Inputs
Programmable yarn tension (100g version 0.5 ÷ 100 gr.
Programmable yarn tension (1000g
version
Programmable alarms
Dimensions
Operating temperature range
Storage temperature
Tension range
IP degree
TS44.. Sensor (DIAPER FEEDER) Technical Characteristics
Power supply voltage
Absorption
Analogue Output
Analogue output resistance
Operating temperature range
Storage temperature
Tension range
Useful tension range
Max applicable tension
Drift error
Repeatability error
Max linearity error
Signaling
Dimensions
24 VDC ± 10%
0.2 A (during normal operation);
1 A (under stress);
3 A (at start-up)
0.3 A 125 VAC
1 A 30 VDC
0-24 VDC
V Max 1,2 VDC
IL
V Min 5 VDC
IH
(resolution 0.1 gr.)
5 ÷ 1000 gr. (resolution 1 gr.)
0.1 ÷ 25 sec.
220 x 86 x 98 mm
10° - 60 °C
-25° - +85° C
0 / full scale
IP54
12 .. 24 Vdc ± 10%
20 mA (max)
100 mV - 10V
1K Ohm
10° - 50 °C
-25° - +85° C
0 - full scale
0% - 95% full scale
10 times the full scale value
0.05% / °C
0.5%
2% (0 - full scale)
With integrated LEDs
50 x 25 x 12.5 mm
