Within the P3 level the following parameters can be programmed:
OFFSET AUTO
MOTOR CALIBRATION
ACCESS CODE
DEVICE IDENTIFICATION CODE
Within the P4 level the following parameter can be programmed:
MOTOR ROTATION DIRECTION
SENSOR TYPE
BAUDRATE
(
APPLICATION DIAPERS
(
YARN TYPE ALL YARN OR ELASTIC
LANGUAGE SELECTION
USE OF INTELLIGENT TENSION CONTROL ACCESSORY
Press the (Control) button to switch from one programming level to the next one.
Press (Reset) button to quit the programming environment.
The following pages provide detailed information about the DIAPER FEEDER device
programming.
However, in the MATRIX CUBE application, the parameter programming is always
carried out via SMART MATRIX CUBE terminal, therefore, such information are
merely indicative.
)
)
