P1 Programming Level
The P1 programming level allows you to setup 3 parameters:
1) Device main tension;
2) Tolerance with respect to the main tension;
3) Max deviation time from tolerance band;
With the DIAPER FEEDER in
and hold it down for 3 seconds.
The display will show the
PROGRAM status.
or to continue.
to start programming of parameters belonging to P1 menu.
MAIN TENSION
P1.1
Tension value with which the DIAPER FEEDER device must operate to create the
desired style.
[Allowed values 0.2 ÷ 99.5 grams].
Choose the desired value using:
(to increase the value) or
to confirm.
ERROR TENSION
P1.2
Tolerance band beyond which the machine will be stopped. The error indication
and machine stop occur only if such tolerance is exceeded for the time period set
in the next parameter (
TIME ALARM
(*)
[Allowed values ± 0.0
what concerns the negative tolerance, if the tension is greater than 0.5 gr.,
otherwise it is automatically stepped down, or AUTO)].
(*) Where setting AUTO, the system automatically calculates the error threshold
value as 50% of
MAIN TENSION
value (P1.1), the
ERROR TENSION
need of changing it manually.
Choose the desired value using:
(to increase the value) or
to confirm.
MATRIX CUBE
LFA m/min
status, (LFA nnnn displayed on LCD) press
CONTROL
label and the DIAPER FEEDER will switch to
ADVANCED
(to decrease the value).
).
÷ 99.5 grams (with automatic limitation to 0.4 grams for
. This means that changing the
value too changes accordingly, without the
(to decrease the value).
DIAPER FEEDER Device
ADVANCED MENU P1
MAIN TENSION
