Checking the I/O Signals of SMART MATRIX CUBE Terminal

This function allow you to check the status of SMART MATRIX CUBE external interface signals (PRX, ZPX,
STC).
Checking the I/O Signals of SMART MATRIX CUBE Terminal
SETUP
Enter the SETUP
Select SERVICE.
Select I/O CHECK
This screen shows the status of each external interface
signal (IDLE, ACTIVE, etc.)
To quit the function.
EXIT to resume the
MATRIX CUBE
→ SERVICE →
menu.
SERVICE menu.
I/O CHECK
- 52 -
