Example 3:
Final tension = 4 g
Initial tension = 10 g
N = 100
Choose the desired value using:
(to increase the value) or
to confirm.
K-PID
P2.4
This parameter represents a multiplier that affects the control algorithm depending
on the yarn elasticity characteristics.
[Allowed values 1 ÷ 5] (1 = Rigid Yarn...... 5 = Elastic Yarn)
Choose the desired value using:
(to increase the value) or
to return to the beginning of P2 menu.
to switch to P3 menu.
to return to CONTROL status without programming P3 and P4 menus.
MATRIX CUBE
DIAPER FEEDER Device
(to decrease the value).
(to decrease the value).
- 87 -
